0E1300H0 by zf electronic systems

0E1300H0

ZF Electronic Systems

Switch Snap Action N.O./N.C. SPDT Lever Quick Connect/Faston 15A 250VAC 1118.55VA 0.98N Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp part 0E1300H0 is a high-quality and reliable snap-action switch. It features a single pole double throw (SPDT) configuration with a lever for easy operation. This switch is designed to provide both normally open (N.O.) and normally closed (N.C.) contact options, allowing it to be used in various applications. With a current rating of 15A and a voltage rating of 250VAC, this switch can handle a wide range of electrical loads. It is also capable of withstanding a maximum power rating of 1118.55VA. The quick connect/Faston terminals provide hassle-free and secure connections, ensuring a reliable and efficient electrical connection. Additionally, this switch can be easily mounted using screws for convenient installation. Overall, the ZF Electronics Corp part 0E1300H0 is a durable and versatile switch suitable for a wide range of industrial, automotive, and consumer electronics applications.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.

Search Keywords: 0E1300H0

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
0E1300H0
RoHS:
Yes
HTS:
8536509040
COO:
MX
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
672
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Thermoplastic Nylon/Lever
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
2.36 mm
Operating Force:
0.98 N
Termination Style:
Quick Connect
Dimension:
86.43 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 9,006

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 20 Weeks

Price (CAD)

Qty
Unit Price
5
$8.621
50
$6.324
100
$6.171
250
$6.064
672
$5.819
1,344
$5.697
2,688
$5.452
5,376 +
$5.299
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
