DB1C-A1RC by zf electronic systems
Image is representational - see mfr. specs

DB1C-A1RC

ZF Electronic Systems

Basic/Snap Action Switch-SPDT-NO/NC-5A-125-250VAC-Solder Term 18.5mm Roller Actuator-Gold/Silver Alloy

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics DB1C-A1RC is a Basic/Snap Action Switch-SPDT, NO/NC-, it supports 5A/125-250VAC

Search Keywords: DB1CA1RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB1C-A1RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
560
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Polybutylene Terephthalate/Roller Lever
Contact Rating @ Voltage:
6@250VAC@EN A
Maximum Movement Differential:
0.6 mm
Operating Force:
0.54 N
Termination Style:
Solder
Dimension:
20 x 6.45 x 25.7 mm
Body Orientation:
Straight
IP Rating:
IP50

IN STOCK: 2,121

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
10
$3.19
100
$2.64
250
$2.61
560
$2.20
1,120
$1.79
2,800
$1.78
5,040
$1.77
7,840 +
$1.76
Suppliers Standard Package
