DC1C-H1AA

Switch Snap Action N.O./N.C. SPDT Button PC Pins 6A 250VAC 48VDC 1.96N Thru-Hole Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

DC1C-H1AA is a sealed subminiature snap switch from the DC Series, designed for reliable switching in demanding environments. This single pole SPDT configuration switch features a 5 Amp contact rating (Contact 1) with UL ratings of 5 A at 125/250 VAC and 1 A at 48 VDC, and EN61058 rating of 6 A at 250 VAC. It includes 1.2 x 0.5 mm PCB terminals and offers IP6K7 ingress protection with an operating temperature range of -40°C to 120°C. The switch provides a mechanical life of minimum 1,000,000 operations with a total travel of 1.6 mm and operating force of 50-340 cN. Common applications include industrial controls, automotive systems, and equipment requiring sealed, compact switching solutions.

Search Keywords: DC1CH1AA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DC1C-H1AA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polybutylene Terephthalate/Button
Contact Rating @ Voltage:
6@250VAC@EN A
Maximum Movement Differential:
0.1 mm
Operating Force:
1.96 N
Termination Style:
PC Pins
Body Orientation:
Straight
IP Rating:
IP6K7
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 227

Can Ship immediately

You may purchase all in-stock quantity of 227

Stock lot only: 227

Minimum Order Quantity: 1200

Multiple: 1200

Price (USD)

Qty
Unit Price
1
$1.609
1,200
$1.463
2,400
$1.391
4,800
$1.329
9,600 +
$1.267
