DB1C-B1RC by zf electronic systems
Image is representational - see mfr. specs

DB1C-B1RC

ZF Electronic Systems

The DB1C-B1RC is a subminiature snap action switch from the DB series, rated for 6A at 250VAC and equipped with quick-connect terminals. ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DB1C-B1RC is a subminiature snap action switch designed for applications requiring high precision and repeat accuracy. This switch has an electrical rating of 6A at 250VAC per EN61058-1 and 5A at 125/250VAC per UL1054. It features 2.8 x 0.5mm quick-connect (QC) terminals and requires a maximum operating force of 55 cN. The switch is specified with a maximum pretravel of 4.5 mm and a minimum overtravel of 2.0 mm. As part of the DB1 series, it offers a long mechanical life of up to 15 million cycles, making it a durable and reliable component for various industrial and commercial equipment.

Search Keywords: DB1CB1RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB1C-B1RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
560
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Polybutylene Terephthalate/Roller Lever
Contact Rating @ Voltage:
6@250VAC@EN A
Maximum Movement Differential:
0.6 mm
Operating Force:
0.54 N
Termination Style:
Quick Connect
Dimension:
20 x 6.45 x 29.65 mm
Body Orientation:
Straight
IP Rating:
IP50

IN STOCK: 3,598

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
10
$2.10
100
$1.87
250
$1.85
560
$1.62
1,120 +
$1.61
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
