E13-50H by zf electronic systems

E13-50H

ZF Electronic Systems

Snap Action Switch - SPDT - Lever - 15A@125/250VAC 2A@48VDC - Quick Connect - Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp part E13-50H is a versatile and reliable snap action switch that is designed to be used in various applications. It features a single-pole double-throw (SPDT) configuration with a lever actuator.This snap action switch can handle a maximum current rating of 15A at 125/250VAC and 2A at 48VDC, making it suitable for a range of electrical circuits. It has quick connect terminals for easy and efficient installation.The E13-50H snap action switch is designed for screw mounting, providing a secure and stable connection. With its high-quality construction and precise functionality, this switch is built to withstand heavy-duty use and provide long-lasting performance.Whether in industrial equipment, appliances, or automotive applications, the ZF Electronics Corp part E13-50H snap action switch delivers reliable and efficient switching capabilities.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.

Search Keywords: E1350H

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E13-50H
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
672
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Thermoplastic Nylon/Lever
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
3.56 mm
Operating Force:
0.64 N
Termination Style:
Quick Connect
Dimension:
92.78 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 947

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 20 Weeks

Price (CAD)

Qty
Unit Price
5
$7.457
50
$5.972
100
$5.391
250
$5.328
672
$5.007
1,344
$4.977
2,688
$4.961
5,376 +
$4.931
Suppliers Standard Package
