E19-00M by zf electronic systems
Image is representational - see mfr. specs

E19-00M

ZF Electronic Systems

Snap Action Switch - DPDT - Button w/ferrule - 15A@125/250VAC 2A@48VDC - Quick Connect - Screw Mount ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

E19-00M is a double pole general purpose snap action switch designed for reliable switching in industrial and appliance applications. It features a 15 A current rating at 125/250 VAC with 3/4 HP motor load capability, utilizing a long life coil spring snap action mechanism rated for a minimum of 6000 operations. The switch incorporates a standard ratio actuator with a spring-loaded metal button (M suffix), providing a maximum operating force of 850 g (1.87 lb), operating point of 20.62 ± 0.76 mm, and minimum over-travel of 5.54 mm. Constructed with a general purpose phenolic case, thermoplastic actuating button, copper alloy terminals, and stainless steel springs, it operates at temperatures up to 105°C standard with 150°C versions available. This RoHS compliant switch is commonly used in household appliances, automated assembly lines, brake switches on utility vehicles, industrial door openers, and vending machines.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E19, E19A, E20, E25, E28 and G20 Series.

Search Keywords: E1900M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E19-00M
Alias/AKA:
0E1900M0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
150
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Thermoplastic Nylon/Button
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
0.38 mm
Operating Force:
8.34 N
Termination Style:
Quick Connect
Dimension:
66.67 x 16.28 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2,732

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$11.09
25
$8.61
50
$8.31
150
$8.14
300
$8.10
600
$7.83
1,050 +
$7.47
