MP100701 by zf electronic systems

MP100701

ZF Electronic Systems

Proximity Sensor Magnetic NPN 5V to 24VDC 3-Pin ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MP100701 is a high-quality proximity sensor designed by ZF Electronics Corp. This sensor utilizes magnetic technology and operates on a 5V to 24V DC power supply. The NPN output allows for easy integration into various automation and control systems. With its compact 3-pin design, this proximity sensor is versatile and can be utilized in a wide range of industrial applications. Trust in ZF Electronics Corp for reliable and efficient sensing solutions.

Product Highlights:

  • Anodized Aluminum Housing
  • High-Speed Capability
  • Sinking (open collector) Output
  • South Pole Sensitive
  • M12 Integral Connector Meets IEC 60947-5-2
  • Wire Insulation Material: Polyolefin
  • Operate point: 300 gauss max
  • Release point: 60 gauss min
  • Cabled versions: -40C to 125C operate & storage temp
  • Connectorized versions: -40C to 105C operate & storage temp

Search Keywords: MP100701

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
MP100701
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Box
Type:
Magnetic
Sensing Distance:
N/A
Mounting:
Panel
Output Type:
NPN
Dimension:
25.4 mm
Response Frequency:
N/A
Operating Temperature:
-40 to 105 °C
Terminal Type:
N/A
Typical Operating Supply Voltage:
9,12,15,18 V
Switching Mode:
N/A

IN STOCK: 0

On Order: 1,000   can ship 12/22/25

Factory Lead-Time 20 Weeks

Price (CAD)

Qty
Unit Price
1
$39.906
10
$35.557
25
$33.535
50
$32.357
100
$31.438
250
$31.270
500 +
$29.554
Suppliers Standard Package
Log in for special pricing
Click for Quote
