3296W-1-103 by bourns
Image is representational - see mfr. specs

3296W-1-103

Bourns

Res Cermet Trimmer 10K Ohm 10% 0.5W(1/2W) 25(Elec)Turns 2.19mm (9.53 X 4.83 X 11.55mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3296W-1-103 is a 3/8" square multiturn trimming potentiometer manufactured by Bourns, featuring a sealed cermet element designed for industrial applications. This potentiometer offers a 10 kO standard resistance with ±10% tolerance, infinite resolution, and 25 turns of effective travel, providing precise voltage and resistance adjustability of ±0.01% and ±0.05% respectively. It is rated for 0.5 watts at 70°C with a maximum operating voltage of 300 volts, and features a chevron seal design for environmental protection with dielectric strength of 900 VAC at sea level. The device is qualified to MIL-R-22097 (style RJ24) and MIL-R-39035 (style RJR24), making it suitable for demanding applications in instrumentation, aerospace, and military equipment where reliability and precision adjustment are critical.

Search Keywords: 3296W1103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3296W-1-103
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536308000
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 4.83 x 11.55 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 297

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.73
300
$1.67
500
$1.66
1,000
$1.61
2,500
$1.59
5,000
$1.57
7,500
$1.56
10,000 +
$1.55
Suppliers Standard Package
