3386W-1-500 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3386W-1-500

Res Cermet Trimmer 50 Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turn 3.15mm (9.53 X 4.83 X 9.53mm) Pin Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

3386W-1-500 is a 3/8" square single-turn cermet trimming potentiometer designed for industrial applications requiring precise resistance adjustment. This side-adjust Trimpot features a 50 ohm resistance value with ±10% tolerance, a power rating of 0.5 watt at 85°C, and operates over a temperature range of -55°C to +125°C. The potentiometer offers infinite resolution with a 280° nominal adjustment angle and 310° mechanical angle, along with sealed construction for environmental protection. It is suitable for circuit calibration, tuning, and trimming applications where reliable and repeatable adjustments are required.

Search Keywords: 3386W1500

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3386W-1-500
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
50 Ohm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 4.83 x 9.53 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 75

Ships today, if you order in

You may purchase all in-stock quantity of 75

Stock lot only: 75

Minimum Order Quantity: 120

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$2.527
120
$2.297
300
$2.163
500
$2.112
1,000
$1.906
2,500
$1.875
5,000
$1.864
7,500
$1.854
10,000 +
$1.844
