3500S-2-501L by bourns
Image is representational - see mfr. specs

3500S-2-501L

Bourns

Res Wirewound POT 500 Ohm 3% 2W 10(Elec)/10(Mech)Turns 6.34mm (22.23 X 46.04mm) Solder Lug Panel Mount ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3500S-2-501L is a precision wirewound potentiometer designed for high-accuracy resistance adjustment applications. It features a 10-turn mechanical angle of 3600° ±10° with an effective electrical angle of 3600° ±10°, -0°, and operates with a standard resistance range of 50 to 200 kO with ±3% total resistance tolerance and ±0.20% independent linearity. The potentiometer incorporates a bushing mount with a 3/8"-32 2A thread, sealable construction rated IP 65, and gold-plated solder lugs for reliable connections. Mechanical specifications include a maximum starting and running torque of 0.42 N-cm (0.6 oz.-in.), stop strength of 67.8 N-cm (96 oz.-in.) minimum, and backlash of 1.0° maximum. The device operates over a temperature range of +1°C to +125°C with a temperature coefficient of ±50 ppm/°C maximum, making it suitable for precision instrumentation, control systems, and industrial applications requiring stable, accurate resistance values.

Search Keywords: 3500S2501L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3500S-2-501L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
10(Elec),10(Mech) Turns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
500 Ohm
Tolerance:
3 %
Temperature Coefficient:
±50 ppm/°C
Dimension:
46.04 x 22.23 mm
Operating Temperature:
1 to 125 °C

IN STOCK: 39

Can Ship immediately

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
1
$77.82
5
$69.95
10
$68.00
25
$62.01
50
$61.85
100
$60.50
250 +
$59.07
