4310R-101-103 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

4310R-101-103

Res Thick Film NET 10K Ohm 2% 1.25W ±100ppm/°C BUS Molded 10-Pin SIP Pin Thru-Hole ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

4310R-101-103 is a 10-pin thick film molded SIP (Single In-line Package) bussed resistor network featuring a 10 kO resistance value. This device incorporates 9 thick-film resistors of equal value, each connected between a separate pin and a common bus, with a power rating of 0.20 watt per resistor at 70°C and a package power rating of 1.25 watts. The resistor network offers a temperature coefficient of ±100 ppm/°C for the 50 O to 2.2 MO range, with TCR tracking of 50 ppm/°C, and operates at a maximum voltage of 100 V. It features a low profile design compatible with DIPs and automatic insertion equipment, with a copper solder-coated lead frame and novolac epoxy body material conforming to UL94V-0 flammability standards. Common applications include pull-up/pull-down resistor arrays, bus termination, and digital circuit interfacing where multiple matched resistors are required.

Search Keywords: 4310R101103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
4310R-101-103
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
20
Package Type:
TUBE
Case Size:
N/R
Circuit Designator:
BUS
Number of Resistors:
9
Number of Terminals:
10
Power Rating:
1.25 W
Power Rating per Resistor:
0.2 (1/5) W
Resistance Value:
10 KOhm
Tolerance:
2 %
Temperature Coefficient:
±100 ppm/°C
Termination Style:
Pin
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 0

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 7 Weeks
