83109056

Name: 83109056
Brand: Crouzet Control
SKU: 54684331
Price: 38.35 USD
Availability: OutOfStock

The 83109056 is a protected microswitch featuring a double-break changeover mechanism and front-facing W2 solder connections. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 83109056 is a double-break, snap-action changeover microswitch designed for high reliability. It operates with a maximum force of 4 N and has a nominal current rating of 5 A at 250 V AC, with a thermal rating of 17.5 A. This switch provides a high mechanical life of 10 million operations and functions within a wide ambient temperature range of -40°C to +85°C. Key mechanical specifications include a minimum overtravel of 0.7 mm, a differential travel of 0.5±0.2 mm, and a dual contact gap of 0.4 x 2 mm. With its robust polyamide case and nickel silver contacts, it is suitable for various industrial control and automation applications requiring durable and precise switching.

Product Highlights:

Potential Applications:

Search Keywords: 83109056

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Crouzet Control

Part No:

83109056

Alias/AKA:

831090C2.0

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536509040

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
