EG1224 by e-switch
Image is representational - see mfr. specs

EG1224

E-Switch

Switch Slide SPDT Extended Side Slide PC Pins Bracket Mount/PCB Through Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The EG1224 is a miniature SPDT (Single Pole Double Throw) tactile switch manufactured by E-SWITCH, designed for compact electronic applications requiring reliable switching functionality. It features a rated current of 0.5A at 15VDC, with an operating force of 250±100gf, providing tactile feedback for user interaction. The switch has a compact form factor with dimensions of 12.00 mm length, 8.50 mm width, and 6.50 mm height, making it suitable for space-constrained PCB layouts. Terminal spacing is precisely defined with 4.00 mm pitch between switching contacts, and the device includes a common terminal configuration for standard SPDT switching applications. This switch is commonly used in consumer electronics, industrial control panels, and portable devices where reliable momentary or maintained switching is required.

Search Keywords: EG1224

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
EG1224
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Mounting:
PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Extended Side Slide
Pole Throw Configuration:
SPDT
Switch Configuration:
N/A
Contact Rating @ Voltage:
N/A
Contact Plating:
Silver
Operating Temperature:
-20 to 70 °C
Termination Style:
PC Pins
Dimension:
13.8 x 15.5 x 8.5 mm

IN STOCK: 1,248

Can Ship immediately

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
250
$0.6694
500
$0.6262
1,000
$0.5898
2,500
$0.5479
5,000
$0.5219
7,500
$0.5193
10,000
$0.5166
15,000 +
$0.5141
Suppliers Standard Package
