1830635 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1830635

The 1830635 is a 6-position, 3.81 mm pitch base strip header with a tin contact surface designed for wave soldering applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1830635 is a 6-position base strip header from the MCV 1,5/..-GF product range. It features a nominal current rating of 8 A, a rated voltage (III/2) of 160 V, and a compact pitch of 3.81 mm. This green-colored header has a tin contact surface and is intended for mounting via wave soldering. The component is constructed from PBT insulating material with a V0 flammability rating according to UL 94. Its low-profile design and engagement noses for locking plugs make it suitable for applications requiring secure, space-saving connections.

Search Keywords: 1830635

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1830635
Alias/AKA:
1830635
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
6
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 0

On Order: 1,419   can ship 1/15/27

Minimum Order Quantity: 5

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
5
$6.84
50
$4.56
100
$4.20
300
$4.11
500
$3.98
1,000
$3.97
2,500
$3.96
5,000 +
$3.94
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes

Accessories

1734634

Coding profile - is inserted into the slot on the plug or inverted header - red insulating ...
