AS6M-21KT2PB by idec corporation
Image is representational - see mfr. specs

AS6M-21KT2PB

IDEC Corporation

Switch Key Lock N.O./N.C. DPDT 90° Flat Key 1A 250VAC 250VDC Quick Connect/Solder 250000Cycles Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AS6M-21KT2PB is a round keylock selector switch from the IDEC A6 Series designed for 16mm (5/8") panel mounting in industrial control and signaling applications. This switch features a spring return to center function with DPDT (double-pole, double-throw) contact configuration, providing reliable switching for momentary or maintained operations. It is rated for a maximum voltage of 250V AC/DC with a thermal current of 3A and a minimum applicable load of 5V AC/DC at 1mA, utilizing gold-clad silver contacts for dependable low-level switching performance. The switch is available in both IP40 (dustproof) and IP65 (oiltight) protection ratings, with terminal options including .110" solder or quick connect styles. Common applications include emergency stop circuits, mode selection, and equipment control in manufacturing, automation, and process control systems where reliable keyed operation and spring return functionality are essential.

Search Keywords: AS6M21KT2PB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
AS6M-21KT2PB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Angle of Throw:
90 °
Key Removable Positions:
Right
Switch Configuration:
N.O./N.C.
Pole Throw Configuration:
DPDT
Contact Rating @ Voltage:
1@120VAC 24VDC A
Terminal Type:
Quick Connect/Solder
Bezel Style:
Round
Operating Temperature:
-25 to 55 °C
Body Orientation:
Straight

IN STOCK: 22

Ships today, if you order in

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$33.54
5
$31.54
10
$30.67
25
$29.54
50
$28.68
100
$27.81
250 +
$26.67
