A40315RNZQ by littelfuse/c-k
Image is representational - see mfr. specs

A40315RNZQ

Littelfuse/C&K

1-4 Pole Rotary Switch ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A40315RNZQ is a 4-pole rotary switch from the C&K A Series, designed for multi-position switching applications. This switch features 3 positions with non-shorting (break-before-make) contacts and Q contact material for RoHS compliance. It offers a contact rating of 2.5 A at 125 V AC and 350 mA at 125 V DC, with contact resistance below 20 mO typical. The switch utilizes 3/8-32 thread panel mounting and solder lug terminations, with an operating temperature range of -30°C to 85°C. Common applications include automotive, industrial equipment, and appliances where reliable multi-pole switching is required.

Search Keywords: A40315RNZQ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
A40315RNZQ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
36
Package Type:
TRAY
Number of Positions:
3
Pole Throw Configuration:
4P3T
Actuator Length:
38.1 mm
Dimension:
26.19 x 26.19 x 66.94 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
2.5@125VAC A

IN STOCK: 33

Can Ship immediately

On Order: 124   can ship 9/11/26

Minimum Order Quantity: 5

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$12.49
36
$9.93
72
$9.83
108
$9.54
252
$8.79
504
$8.21
1,008 +
$7.99
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
