G6A-234P-ST-US-DC24 by omron electronics

G6A-234P-ST-US-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT(20.2x10.1x8.4)mm THT ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G6A-234P-ST-US-DC24 is a Non-latching Low Signal Relay with DC coil. This G6A-series signal relay has DPDT AgPd (Au clad) contacts. Low-profile design allows use in 12.7mm (0.5 inch) PC board rack. Surge withstand voltage meets FCC Part 68 regulation. Unique moving loop (permanent magnet) armature reduces relay size, magnetic interference and contact bounce time. High sensitivity can be driven by digital circuits Units can be mounted side by side due to low magnetic leakage Special models available for ultrasonic cleaning and low thermo electromotive force -40 to 70°C Operating temperature range Applications Industrial

Search Keywords: G6A234PSTUSDC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6A-234P-ST-US-DC24
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Box
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 10.1 x 8.4 mm
Termination Style:
PC Pin
Coil Current:
8.3 mA
Contact Form:
2 Form C

IN STOCK: 4,089

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
5
$8.116
50
$7.136
100
$6.845
250
$6.463
500
$6.171
1,000
$5.880
2,500
$5.498
5,000 +
$5.374
