AQY212EH by panasonic electronic components
Image is representational - see mfr. specs

AQY212EH

Panasonic Electronic Components

Solid State Relay 50mA 1.5V DC-IN 0.55A 60V AC/DC-OUT 4-Pin DIP Tube ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AQY212EH is a DIP4-pin PhotoMOS relay featuring reinforced insulation rated at 5,000 Vrms with more than 0.4 mm internal insulation distance between inputs and outputs, conforming to EN41003 and EN60950 standards. This device is designed to control low-level analog signals with extremely low closed-circuit offset voltage, enabling distortion-free signal transmission. It offers high sensitivity with a maximum continuous load current of 0.55 A at 60 V peak AC load voltage, combined with low on-resistance of 0.25 O typical and 0.5 O maximum. The relay exhibits low off-state leakage current of maximum 1 µA and operates reliably across an ambient temperature range of -40°C to +85°C. Typical applications include modem and telephone equipment, industrial plant control, security systems, and sensing equipment where galvanic isolation and low-signal switching are required.

Search Keywords: AQY212EH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQY212EH
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Output Type:
AC,DC
Maximum Output Voltage:
60 V
Maximum Output Current:
0.55 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
4.78 x 6.4 x 3.2 mm

IN STOCK: 520

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
10
$1.478
50
$1.474
100
$0.986
300
$0.943
500 +
$0.924
Suppliers Standard Package
