EXB-S8V103J by panasonic

EXB-S8V103J

Panasonic

Res Thick Film Array 10K Ohm 5% ±200ppm/°C ISOL 8-Pin 2008(4 X 0805) Concave SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC part EXB-S8V103J is a resistor that is designed to provide precise and reliable performance in various electronic applications. It features a thick film array with a resistance value of 10K Ohm and a tolerance of 5%. The resistor has a temperature coefficient of ±200ppm/°C, ensuring stable operation even in extreme temperature conditions. With its 8-pin 2008 package (consisting of 4 X 0805), this resistor is designed for surface mount installation, making it convenient and space-saving. The concave design of the resistor enhances its durability and resistance to physical stress. This Panasonic resistor is supplied in tape-and-reel packaging for ease of handling and assembly in production processes.

Search Keywords: EXBS8V103J

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
EXB-S8V103J
RoHS:
Yes
HTS:
8533210020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500
Package Type:
Reel
Case Size:
2008
Circuit Designator:
ISOL
Number of Resistors:
4
Number of Terminals:
8
Power Rating:
N/A
Power Rating per Resistor:
0.1 (1/10) W
Resistance Value:
10 KOhm
Tolerance:
5 %
Temperature Coefficient:
±200 ppm/°C
Termination Style:
Concave

IN STOCK: 9,400

Ships today, if you order in

On Order: 80,000   can ship 12/24/25

Minimum Order: 2500

Multiple: 2500

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
2,500
$0.2403
5,000
$0.2391
7,500
$0.2379
10,000
$0.2365
25,000
$0.2355
50,000
$0.2343
100,000 +
$0.2331
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
