1681486

Name: 1681486
Brand: Phoenix Contact
SKU: 12136793
Price: 131.94 USD
Availability: InStock

Connector - Universal - 5-position - Socket straight M12 - A-coded - Screw connection - knurl material: Zinc die-cast - nickel-plated - cable gland Pg9 - external cable diameter 6 mm ... 8 mm ...

View Datasheet

Ask the Datasheet

RoHS Compliant

DESCRIPTION

1681486 is a 5-position, straight socket, universal M12 connector. This A-coded connector is screw connected, which is a proven connection technology for a large selection of different conductors. Contact material is made of Copper Zinc in bright alloy/white bronze finish and knurl material is nickel plated zinc die-cast. The product has Pg9 cable glands, housing diameter of 20mm, length of 54mm, and external cable diameter of 6mm to 8mm. Conductor cross section is 18 to 24AWG.

Product Highlights:

Potential Applications:

Search Keywords: 1681486

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

1681486

Alias/AKA:

1681486

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694020

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
