1757284
Phoenix ContactPCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 6 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm ...
DESCRIPTION
The PHOENIX CONTACT part 1757284 is a set of PCB headers designed for electrical connections. They have a high nominal current rating of 12 A, allowing for the transfer of large amounts of electricity. With a rated voltage of 320 V (III/2), they can handle powerful electrical systems. These PCB headers have a nominal cross section of 2.5 mm², ensuring a secure and reliable connection. They feature 6 positions and a pitch of 5.08 mm, allowing for easy installation and compatibility with various PCB configurations. The green color of these headers adds a visual aesthetic to your PCB layout. The contact surface is coated with tin, increasing conductivity and preventing corrosion. These headers are specifically designed for wave soldering, providing a straightforward and efficient mounting process. The pin layout is linear, allowing for easy alignment and soldering. The solder pins have a length of 3.5 mm, providing a suitable surface for soldering and ensuring a solid connection. Overall, the PHOENIX CONTACT part 1757284 PCB headers offer high current capabilities, reliable performance, and ease of installation, making them an ideal choice for electronic applications.
Search Keywords: 1757284
SPECIFICATIONS
IN STOCK: 1,845
Ships today, if you order in
Manufacturer Stock: 9,085 can ship 12/5/25
Minimum Order: 100
Multiple: 100
Factory Lead-Time 10 Weeks can ship 1/29/26
Price (CAD)
Tools/3D Models
Product Guides
Datasheet
Product Changes
PCN - 01-Jan-2015 - INTRODUCTION OF 2D BARCODING
