1757381 by phoenix contact

1757381

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 16 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1757381 is a high-quality PCB header with a nominal current of 12 A. It is designed to handle a rated voltage of 320 V and has a nominal cross-section of 2.5 mm². With 16 positions and a pitch of 5.08 mm, this green-colored header offers excellent connectivity options for your PCB projects. The contact surface is coated with tin for enhanced durability and conductivity. It is designed for easy and secure mounting through wave soldering. The pin layout follows a linear pinning pattern, with 3.5 mm solder pins for reliable connections.

Search Keywords: 1757381

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1757381
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
16
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 0

On Order: 400   can ship 1/14/26

Minimum Order: 5

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
5
$6.427
25
$5.696
100
$5.047
250
$4.779
500
$4.707
1,000
$4.584
2,500
$4.522
5,000 +
$4.450
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
