1777141 by phoenix contact

1777141

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 9 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1777141 is a high-quality PCB header designed to provide reliable and secure connections in a variety of applications. With a nominal current of 12 A and a rated voltage of 320 V, this header is capable of handling high power and voltage requirements. Featuring a nominal cross section of 2.5 mm² and nine positions, this header offers ample space for connecting multiple wires or components. The pitch of 5.08 mm ensures easy and efficient installation, while the green color adds visibility and aesthetic appeal to your PCB design. The contact surface is coated with tin, ensuring excellent conductivity and resistance to corrosion. The header is designed to be mounted using wave soldering methods, making it a convenient choice for production processes. The linear pinning layout ensures a straightforward and organized arrangement of pins, while the solder pin with a length of 3.9 mm provides a stable and secure connection. Trust PHOENIX CONTACT for reliable and high-performance PCB headers that meet your specific needs.

Search Keywords: 1777141

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777141
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
9
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 176

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 10 Weeks

Price (CAD)

Qty
Unit Price
5
$9.601
25
$8.514
100
$7.549
300
$7.044
500
$6.937
1,000
$6.830
2,500
$6.738
5,000 +
$6.631
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
