1792061 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1792061

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 7 - pitch: 5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1792061 is a PCB connector designed for various applications. It has a nominal current rating of 12 A and a rated voltage of 320 V. The connector features 7 positions with a 2.5 mm² nominal cross-section and a 5 mm pitch. The connection method is screw connection with tension sleeve, ensuring secure and reliable connections. The connector is color-coded green for easy identification and has a contact surface coated with tin for enhanced conductivity and corrosion resistance.

Search Keywords: 1792061

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1792061
Alias/AKA:
1792061
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5 mm
Number of Circuits:
7
Maximum Voltage Rating:
250@IEC,300@UL V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

IN STOCK: 102

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$12.75
25
$8.63
50
$8.16
100
$7.97
250
$7.73
500
$7.70
1,000
$7.68
2,500 +
$7.66
