1805314

Phoenix Contact

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1805314 is a PCB connector that is designed to provide efficient and reliable electrical connections. With a nominal current of 12 A and a rated voltage of 320 V, this connector is suitable for a wide range of applications. Featuring a nominal cross section of 2.5 mm², the connector has three positions and a pitch of 5.08 mm, providing ample space for multiple connections. The connection method of this connector is a screw connection with a tension sleeve, ensuring secure and stable connections. The color of the connector is green, which makes it easily distinguishable in various applications. For enhanced performance and durability, the contact surface of the connector is made of tin, ensuring excellent conductivity and resistance to corrosion. Overall, the PHOENIX CONTACT part 1805314 is a reliable and efficient PCB connector that offers a convenient and secure solution for electrical connections.

Search Keywords: 1805314

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1805314
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Panel Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
3
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

IN STOCK: 100

Can Ship immediately

Minimum Order: 50

Multiple: 50

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
50
$3.780
100
$3.739
250
$3.718
500
$3.708
1,000
$3.687
2,500
$3.667
5,000 +
$3.646
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
