5-103168-8 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5-103168-8

A 20-position, double-row, shrouded vertical header with straight posts on a .100 x .100 inch centerline for board-to-board connections. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5-103168-8 is a 20-position, double-row, shrouded vertical header from the AMPMODU Interconnection System. It features .025 inch square straight posts arranged in a .100 x .100 inch grid. The copper alloy contacts have duplex plating with .000030 inches of gold on the contact area and tin on the solder tails, all over a nickel underplate. Housed in a black, 94V-0 rated flame-retardant thermoplastic with detent windows, this header ensures secure and reliable mating. It is designed for board-to-board applications such as mother/daughter board connections and other subassembly interconnections.

Product Highlights:

  • Header
  • Header Type = Shrouded
  • Number of Rows = Dual
  • Number of Positions = 20
  • Mating Post Length = 8.08 mm

Search Keywords: 51031688

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-103168-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
176
Package Type:
TRAY
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
20
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C
