1829413 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1829413

Feed-through header - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 10 - pitch: 3.81 mm - connection method: Solder/Slip-on connection - color: green - contact surface: Tin - mounting: Direct mounting - pin layout: Linear pinning - solder pin [P]: 9.4 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1829413 is a feed-through header designed for applications requiring a nominal current of 8 A and a rated voltage of 160 V. This header has 10 positions with a 1.5 mm² nominal cross section and a pitch of 3.81 mm. It features a solder/slip-on connection method and a green color. The contact surface is tin-plated, and it is designed for direct mounting with a linear pinning layout. The solder pin on this header has a length of 9.4 mm.

Search Keywords: 1829413

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1829413
Alias/AKA:
1829413
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
PL
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Type:
Wire to Wire
Body Orientation:
Straight
Gender:
HDR
Mounting:
Wall Mount
Pitch:
3.81 mm
Number of Contacts:
10
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 153

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
5
$11.26
25
$10.07
50
$9.98
100
$9.88
250
$9.86
500
$9.83
1,000 +
$9.81
Supplier's Standard Package
Log in for special pricing
