1830622 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1830622

The 1830622 is a 5-position, single-row PCB header with a 3.81 mm pitch, designed for wave soldering and featuring a threaded flange for secure mounting. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1830622 is a 5-position PCB header from the MCV 1,5/..-GF product family, providing vertical connection to a printed circuit board. It is rated for a nominal current of 8 A and a voltage of 160 V (III/2), with a compact 3.81 mm pitch. The header is designed for wave soldering and features a linear pin layout with tin-plated contacts and a PBT housing with a V0 flammability rating. A threaded flange allows for screw locking, ensuring superior mechanical stability. As part of the COMBICON MC 1,5 plug-in system, this header offers design flexibility for a wide range of industrial applications.

Search Keywords: 1830622

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1830622
Alias/AKA:
1830622
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Type:
Wire to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
5
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A
  Possible Replacement options available.  See Alternatives

IN STOCK: 85

Ships today, if you order in

On Order: 250   can ship 5/3/27

Minimum Order Quantity: 10

Factory Lead-Time 37 Weeks
