ADF04ST04

Switch DIP OFF ON SPST 4 Flush Slide 0.1A 24VDC Gull Wing 2.54mm SMD T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

ADF04ST04 is a mechanical DIP switch designed for surface mount PCB applications. It features a single pole single throw (SPST) configuration with a flush slide actuator style, making it suitable for compact electronic designs. The switch is part of the ADF-SMT series from TE Connectivity and is RoHS/ELV compliant. Common applications include configuration settings, mode selection, and user interface controls in electronic devices where reliable mechanical switching is required.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Surface Mount
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Flush, Slide
  • Sealed

Search Keywords: ADF04ST04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADF04ST04
Alias/AKA:
1-1825059-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
35
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Flush Slide
Actuator Length:
0 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.1@24VDC A
Contact Plating:
Gold Flash
Terminal Pitch:
2.54 mm

IN STOCK: 32,352

Can Ship immediately

Minimum Order Quantity: 35

Multiple: 35

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
35
$1.515
280
$1.496
525
$1.484
1,015
$1.477
2,520
$1.474
5,005
$1.025
7,525
$1.023
10,010 +
$1.020
