2761499 by phoenix contact

2761499

Phoenix Contact

D-SUB plug - 9-pos. female connector - one cable entry < 35° - universal type for all systems - pin assignment: 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 to screw connection terminal block

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2761499 is a 9-position female D-sub Bus PCB Connector with the screw connection method and <35° one cable entry. This 2761499 connector supports RS-232, RS-422, RS-485 signals. The housing is made of metal-plated ABS.

Search Keywords: 2761499

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2761499
RoHS:
Yes
HTS:
8536694030
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature/Terminal Block
Body Orientation:
N/A
Gender:
F
Pitch:
N/A
Number of Contacts:
9
Operating Temperature:
-20 to 75 °C

IN STOCK: 51

Can Ship immediately

Manufacturer Stock: 405   can ship 12/8/25

Factory Lead-Time 4 Weeks can ship 12/22/25

Price (CAD)

Qty
Unit Price
1
$106.099
3 +
$100.787
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

1204504

Actuation tool - for ST terminal blocks - also suitable for use as a bladed screwdriver - ...

1772793

Crimping pliers - for IBS DSUB.../C

1652651

D-SUB contact insert - shell size 1 - with nine signal contacts - type of contact pin - ge ...

2761509

D-SUB connector - 9-pos. - male connector - one cable entry < 35° - universal type for all ...

2799694

Optional mounting screw - without knurl for narrow installation conditions - slotted head ...
