3004265 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

3004265

Fuse terminal block for cartridge fuse insert - cross section: 0.5 - 16 mm² - AWG: 26 - 8 - width: 10.2 mm - color: black ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3004265 is a Disconnect Type Fuse. Number of Positions 2 Number of Levels 1 Terminal - Width 10.2mm Termination Style Screw Current - IEC 10A Voltage - IEC 500V Current - UL 10A Voltage - UL 600V Wire Gauge or Range - AWG 8-26 AWG Wire Gauge or Range - mm² 0.5-16mm² Features LED Fuse Type 6.3mm x 32mm Material - Insulation Polyamide (PA), NylonType: Wire to Wire Color: Black Length: 79 mm Width: 10.2 mm Height: 65 mm

Search Keywords: 3004265

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3004265
Alias/AKA:
3004265
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
TR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Contact Plating:
N/A
Contact Material:
N/A
Family:
3004265
Body Orientation:
N/A
Housing Color:
Black
Gender:
F
Dimension:
79mm x 10.2mm x 68 mm

IN STOCK: 93

Ships today, if you order in

On Order: 100   can ship 11/20/26

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$23.04
50 +
$21.89
Supplier's Standard Package
