1375820-3 by te connectivity / amp brand
Image is representational - see mfr. specs

1375820-3

TE Connectivity / AMP Brand

CST-100 II HOUSING 3 POS ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1375820-3 is a 3-position CST-100 II connector housing designed for wire-to-board interconnect applications. The housing is manufactured from UL 94V-0 rated nylon in white color and features a 2.54 mm (0.100 inch) centerline spacing with dimension A of 0.320 inches (8.13 mm). It is rated for 250 VAC voltage and 4 amp maximum current, with an operating temperature range of -55°C to +105°C. The connector offers low-level resistance of 6 mO maximum initial and 10 mO maximum final, along with insulation resistance of 1000 MO minimum initial and 100 MO minimum final. This housing is commonly used in printed circuit board applications where reliable wire-to-board connections are required.

Product Highlights:

  • CST-100 II Housings
  • Number of Positions = 3
  • Mating Type = Receptacle
  • Wire-to-Board Application
  • 2.54 mm Contact Centerline Spacing

Search Keywords: 13758203

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1375820-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
3
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
4/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,002,954

Can Ship immediately

Minimum Order Quantity: 250

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
250
$0.1096
2,500
$0.0750
5,000
$0.0737
7,500
$0.0703
25,000
$0.0700
50,000
$0.0696
100,000
$0.0653
150,000 +
$0.0650
