1-480318-9 by te connectivity / amp brand
Image is representational - see mfr. specs

1-480318-9

TE Connectivity / AMP Brand

02P CMNL PLUG HSG F/H BLK ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-480318-9 is a 2-circuit in-line socket housing (plug) designed for use in Commercial MATE-N-LOK connector systems. This free-hanging housing features a positive lock mechanism and is constructed from UL94V-2 rated nylon in natural color. The housing has dimensions of A: 0.610 in (15.49 mm), B: 0.930 in (23.62 mm), C: 0.330 in (8.38 mm), D: 0.530 in (13.46 mm), E: 0.860 in (21.84 mm), and F: 0.295 in (7.49 mm), with a 0.200 in (5.08 mm) centerline spacing. This connector housing is commonly used in wire-to-board applications and mates with pin housing 1-480319-0, making it suitable for power circuit connections in various electronic assemblies.

Product Highlights:

  • Housing
  • Contact Diameter = 2.13 mm
  • Number of Circuits = 2
  • 5.08 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 14803189

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-480318-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10000
Package Type:
Bag
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
PL
Number of Contacts:
2
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
13/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 25,340

Can Ship immediately

Minimum Order Quantity: 100

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
100
$0.3775
500
$0.3583
1,000
$0.3479
2,500
$0.3433
5,000
$0.3417
7,500
$0.3408
10,000
$0.3399
20,000 +
$0.3391
Suppliers Standard Package
