1586512-2 by te connectivity / amp brand
Image is representational - see mfr. specs

1586512-2

TE Connectivity / AMP Brand

02P CMNL HDR ASSY PC NATL LF ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1586512-2 is a 2-circuit wire-to-board power connector from the 5.0 mm Power Key Connectors (5.0 PKC) family, designed for power circuits in home appliances, particularly gas appliances. The connector features a compact design with a 19.4 mm mated height and 5.0 mm contact centerline spacing, incorporating a detent lock mechanism for secure contact retention. The housing utilizes FH UV Stable socket contacts paired with FH Positive Lock pin contacts, with a pre-tin duplex finish (gold plating in mating area over nickel underplate with matte tin on solder tail). The connector includes protective walls surrounding locking levers to prevent tangling with wires and is designed to release bubbles created during potting processes. It is recognized under UL Component Program (File No. E28476) and certified by Canadian Standards Association (File No. LR7189), with a flammability rating of UL94V-2, making it suitable for demanding power distribution applications requiring reliable electrical connections.

Product Highlights:

  • Connector
  • With Contacts
  • Housing Gender = Header - Pin
  • Contact Gender = Pin
  • Through Hole Contact Termination Type

Search Keywords: 15865122

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1586512-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
250,250 VDC|VAC
Maximum Current Rating:
13/Contact A
Operating Temperature:
-55 to 85 °C

IN STOCK: 2,725

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$1.28
100
$1.16
250
$1.14
500
$1.11
1,000
$1.09
2,500
$1.07
5,000
$1.05
10,000 +
$1.04
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

1-480318-0

Rectangular Connector Housing - Plug - Female Socket - 2 Positions - 0.200" (5.08mm) Pitch ...

1-480318-4

02P CMNL PLUG HSG F/H YELL

1-480318-9

02P CMNL PLUG HSG F/H BLK

Show 1 More
