1-5747871-4 by te connectivity / amp brand

1-5747871-4

TE Connectivity / AMP Brand

D Sub Connector - 9 Contacts - Plug - Through Hole - DE - AMPLIMITE HD-20 Series - Steel Body. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-5747871-4 is a 9-way 2-row front metal-shell D-sub Plug with gold-plated brass contacts and fixed zinc female screwlocks. The Amplimite HD-20 series straight posted plug comes with grounding indents, black thermoplastic housing, tin-plated steel shell, brass threaded inserts and tin-plated solder tail. Plugs are preloaded with size 20 DF posted pin contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308.

Product Highlights:

  • 9 Positions
  • With Contacts
  • Housing Gender = Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20

Search Keywords: 157478714

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5747871-4
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 205

Can Ship immediately

Minimum Order: 17

Multiple: 17

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
17
$4.429
51
$4.357
102
$4.223
255
$4.141
510
$4.120
1,003
$4.099
2,516 +
$4.079
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1-747943-5

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1-745491-9

RCPT ASSY,9P,HDE,MS

1-747943-6

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1658610-4

9 Position D-Sub Receptacle, Female Sockets Connector

1-745491-7

09 HDE MS RCPT,22-26,LEAD FREE

1-745491-6

09 HDE MS RCPT,26-30,LEAD FREE

1658612-4

09 POS HDF RCPT, MS, LEAD FREE

5746861-4

9 POS HDF RCPT, MS

747516-7

09 HDE PMOLD RCPT, LEAD FREE

Show 7 More
