1-745491-9

TE Connectivity / AMP Brand

RCPT ASSY,9P,HDE,MS ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-745491-9 is an AMPLIMITE HDE-20 series D-subminiature receptacle connector designed for reliable cable termination applications. This connector features 9 contact positions in a shell size 1 configuration with dimensions of 1.213 inches (Dim. A) and 0.984 inches (Dim. B), and is preloaded with insulation displacement socket contacts for 26-22 AWG wire. The connector utilizes a 94V-0 rated thermoplastic insert in black and accepts wire with a maximum insulation thickness of 0.015 inches and maximum insulation diameter of 0.060 inches. It is designed for terminating solid or stranded wire (7 strand max) with individual conductor strands larger than 0.005 inch diameter. Common applications include industrial machinery, medical instrumentation, computers and peripherals, and data storage systems where reliable D-subminiature connections are required.

Product Highlights:

  • Connector
  • Product Series = HDE-20 (IDC)
  • Number of Positions = 9
  • Receptacle
  • With Contacts

Search Keywords: 17454919

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-745491-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
55
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 211

Ships today, if you order in

MOQ for In Stock Qty: 55

MOQ for out of Stock Qty: 660

Multiple: 55

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
55
$11.04
110
$11.02
275
$10.99
550
$10.96
660
$10.94
1,320
$5.77
1,980
$3.97
2,640 +
$3.89
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories
