1-644752-5 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-644752-5

15P MTA156 HDR ASSY SQ STR F/L ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

15P MTA156 HDR ASSY SQ STR F/L

Product Highlights:

  • Header
  • 15 Positions
  • Preloaded
  • Header Gender = Plug
  • Contact Gender = Pin

Search Keywords: 16447525

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-644752-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Package Type:
BAG
PCB Mount Retention:
Without
Connector & Housing Type:
Plug
Contact Base Material:
Copper Alloy
Number of Power Positions:
15
Mating Retention:
With
UL Flammability Rating:
UL 94V-0
Circuit Application:
Power
Housing Material:
Polyester - GF
Contact Layout:
Inline
Number of Positions:
15
Connector & Contact Terminates To:
Printed Circuit Board
Panel Mount Feature:
Without
Connector Mounting Type:
Board Mount
Packaging Method:
Package
Contact Retention Within Housing:
Without
Sealable:
No
Mating Retention Type:
Friction Lock
Contact Underplating Material:
Nickel
PCB Mount Orientation:
Vertical
PCB Contact Termination Area Plating Material:
Tin
Packaging Quantity:
1
Strain Relief:
Without
Glow Wire Rating:
Standard Part - Not Glow Wire
Contact Current Rating (Max):
7 A
PCB Mount Alignment:
Without
Number of Rows:
1
Rectangular Power Connector Type:
Header
Mating Alignment:
Without
Housing Color:
Natural
Connector System:
Wire-to-Board
UL Rating:
Recognized
Contact Mating Area Plating Material:
Tin
Operating Voltage:
600 VAC
Termination Method to Printed Circuit Board:
Through Hole - Solder
Contact Type:
Pin
Header Type:
Partially Shrouded
Centerline (Pitch):
.156 in, 3.96 mm
Mating Post Length:
.4 in, 10.16 mm
Termination Post & Tail Length:
.175 in, 4.45 mm
PCB Thickness (Recommended):
1.6 in, .06 mm
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
Contact Mating Area Plating Material Thickness:
100 µin, 2.54 µm
Approved Standards:
UL E28476
Connector Height:
.525 in, 13.34 mm
Product Length:
2.34 in, 59.44 mm
Agency/Standard:
CSA , UL , VDE
PCB Contact Termination Area Plating Material Thickness:
100 µin, 2.54 µm
CSA Rating:
Certified , LR 7189
Contact Underplating Material Thickness:
1.27 µin, 50 µm

IN STOCK: 0

Minimum Order Quantity: 25

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$1.504
250
$1.222
500
$1.167
1,000
$0.789
2,500
$0.756
5,000
$0.736
7,500
$0.716
10,000 +
$0.644
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
