173977-3 by te connectivity / amp brand
Image is representational - see mfr. specs

173977-3

TE Connectivity / AMP Brand

CT CONN MT REC ASSY 3P ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

173977-3 is a 3-position cable-mounted receptacle assembly from the ELCON Hybrid Mini-Drawer Connector series. The housing is constructed from glass-filled P.B.T. thermoplastic with pre-tinned phosphor bronze contacts, supporting wire sizes of AWG #28-26 (0.08-0.15 mm²) with insulation diameters of 0.85-1.05 mm. Key dimensions include A = 4.0 mm, B = 6.8 mm, and C = 8.0 mm. This connector is part of a true hot-plug, blind-mating system designed for mixed signal and power applications. Typical applications include low noise power supplies, switch-mode power supplies (SMPS), power factor-correcting (PFC) power supplies, and redundant (N+1) power systems.

Product Highlights:

  • Connector
  • Connector Type = Blindmate, MT (Mass Termination)
  • Mating Type = Receptacle
  • Number of Positions = 3
  • Number of Rows = 1

Search Keywords: 1739773

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
173977-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Bag
Type:
IDC Connector
Body Orientation:
Straight
Gender:
RCP
Mounting:
Cable Mount
Pitch:
2 mm
Number of Contacts:
3
Maximum Voltage Rating:
125,125 VDC|VAC
Maximum Current Rating:
2/Contact A
Termination Method:
IDT
Operating Temperature:
-40 to 105 °C

IN STOCK: 286,624

Ships today, if you order in

Minimum Order Quantity: 250

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
250
$0.1725
2,000
$0.1360
4,000
$0.1337
6,000
$0.1311
10,000
$0.1286
26,000
$0.1283
50,000
$0.1280
100,000 +
$0.1277
Suppliers Standard Package
