1-770872-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-770872-0

Wire-To-Board Connector - 4.14 mm - 2 Contacts - Plug - Mini Universal MATE-N-LOK Series - Through Hole. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1-770872-0 power connector from TE Connectivity is perfect for powering your circuit because it comes with the least amount of losses. This HDR connector's 2 contacts that are made out of brass and plated with tin over nickel. This connector has a single port. It has a straight body orientation. Its pitch is 4.14 mm. It has a header type gender. It has a maximum voltage rating of 600 VAC. 1-770872-0 is housed in nylon. This device has a maximum current rating of 9.5 A/contact. This product is 13.69 mm long, 14.25 mm tall and 6.35 mm deep. Its 2 terminals use the solder termination method.

Product Highlights:

  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 2
  • 4.14 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 17708720

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770872-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
BAG
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A

IN STOCK: 10,600

Ships today, if you order in

Minimum Order Quantity: 200

Multiple: 200

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
200
$0.774
400
$0.756
600
$0.754
1,000
$0.731
2,600
$0.714
5,000
$0.712
7,600
$0.710
10,000 +
$0.709
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes
