1-794617-2 by te connectivity / amp brand

1-794617-2

TE Connectivity / AMP Brand

Connector Housing - Micro MATE-N-LOK Series - Receptacle - 12 Ways - 3 mm - Micro MATE-N-LOK Connectors. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-794617-2 is a 12-position 2-row black Receptacle Housing, made of nylon 66/6 and is used with micro MATE-N-LOK connectors. The connectors with dual locking lances provide optimum contact stability pins and sockets can be intermixed in the same housing.

Product Highlights:

  • Housing
  • Housing Type = Receptacle
  • Number of Positions = 12
  • Number of Rows = Dual
  • 3.00 mm Centerline

Search Keywords: 17946172

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-794617-2
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
12
Maximum Voltage Rating:
250,250 VDC|VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C

IN STOCK: 13,208

Ships today, if you order in

Minimum Order: 50

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
50
$0.4716
500
$0.3471
1,000
$0.3433
2,500
$0.3317
5,000
$0.3300
7,500
$0.3284
10,000
$0.3267
15,000 +
$0.3251
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
