1909763-1 by te connectivity / amp brand

1909763-1

TE Connectivity / AMP Brand

RF / Coaxial Connector - UMCC Coaxial - Straight Jack - Surface Mount Vertical - 50 ohm - Copper Alloy. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1909763-1 Mini RF Header from TE Connectivity is a single port UMCC vertical surface mount PCB jack. Copper alloy contact plated with gold on mating area, gold flash on solder tails and nickel under plated. This coaxial connector has high temperature LCP (Liquid Crystal Polymer) housing and operating temperature range -40°C to 90°C.

Search Keywords: 19097631

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1909763-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
Reel
Type:
Coaxial
Impedance:
N/A
Operating Frequency:
N/A
Gender:
PL
Mounting:
Surface Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
N/A
Dimension:
3 x 1.25 mm

IN STOCK: 76,366

Ships today, if you order in

Minimum Order: 1000

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1,000
$0.3173
2,500
$0.3094
5,000
$0.3063
10,000
$0.3048
25,000
$0.3031
50,000 +
$0.3017
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
1566230-1
1566230-1
VIEW PRODUCT

Tools/3D Models

Product Guides

Product Changes
