1-969508-2 by te connectivity / amp brand

1-969508-2

TE Connectivity / AMP Brand

6POS MQS REC COD A ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 1-969508-2 is a high-quality connector designed for reliability and efficient performance in electrical systems. Featuring a 6-position format, this MQS (Micro Quadlock System) receptacle connector is coded with an 'A' designation for precise application matching. The compact design ensures space-saving installation while maintaining robust connection integrity. Ideal for automotive, industrial, or any application requiring secure and efficient electrical connections, this connector is engineered for ease of use and longevity. Its durable construction supports stable connectivity solutions, ensuring optimal performance even in demanding conditions. Discover seamless integration and top-tier connectivity with this exceptional component from TE Connectivity.

Search Keywords: 19695082

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-969508-2
RoHS:
Yes
HTS:
8538906000
COO:
HU
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
Carton
Connector & Housing Type:
Housing for female terminals
Primary Product Color:
Black
Serviceable:
Yes
Sealable:
No
Connector Position Assurance Capable:
No
Primary Locking Feature:
On the Terminal
Circuit Application:
Signal
Operating Voltage:
24 VDC
Number of Positions:
6
Number of Rows:
1
Terminal Position Assurance:
Yes
Cable Exit Angle:
180°
Product Length:
.697 in, 17.7 mm
Centerline (Pitch):
.1 in, 2.54 mm
Mating Tab Width:
.025 in, .63 mm
Product Width:
.63 in, 16 mm
Nominal Voltage Architecture:
12 V, 24 V
Mating Alignment:
With
Connector System:
Wire-to-Board , Wire-to-Wire
Strain Relief:
Without
Housing Material:
PBT GF10
Connector Shape:
Rectangular
Connector Mounting Type:
Cable Mount (Free-Hanging)
Operating Temperature Range:
-40 – 120 °C, -40 – 248 °F
Contact Current Rating (Max):
7.5 A
Operating Temperature (Max):
120 °C, 248 °F
Contact Type:
Socket
Contact Size:
.63mm
Connector Height:
.417 in, 10.6 mm
Connector & Contact Terminates To:
Wire & Cable
Mating Alignment Type:
Keyed

IN STOCK: 4,430

Ships today, if you order in

Minimum Order: 50

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
50
$0.822
500
$0.690
1,000
$0.629
2,500
$0.606
5,000
$0.582
10,000
$0.575
15,000
$0.572
25,000 +
$0.570
