5-747904-8 by te connectivity / amp brand
Image is representational - see mfr. specs

5-747904-8

TE Connectivity / AMP Brand

9 Plug Solder Cup, G/F w/ CN, ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5-747904-8 is a 9-position D-sub plug assembly connector designed for use in the AMPLIMITE series. It features a current rating of 3 amperes, dielectric withstanding voltage of AC 1000V r.m.s., and insulation resistance of 5000 megohms minimum at DC 500V. The connector includes clinch nuts, grounding indents, brass contacts with gold plating on contact areas, and solder cups that accommodate up to 20 AWG wire. The front and back insulators are constructed from PBT with 30% glass fiber, rated UL94V-0 in black color. This plug assembly mates with any 9-position receptacle in the AMPLIMITE series, making it suitable for data communication and industrial control applications requiring reliable electrical connections.

Product Highlights:

  • Connector
  • Product Series = HD-20 (Solder Cup)
  • 9 Positions
  • Without Enclosure
  • Housing Gender = Plug

Search Keywords: 57479048

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-747904-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tray
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Solder Cup
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 6,809

Can Ship immediately

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 1500

Multiple: 50

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
50
$3.89
250
$3.49
500
$3.33
1,000
$3.16
1,500
$3.07
3,000
$2.96
4,500
$2.95
6,000 +
$2.94
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models
