201580-1 by te connectivity / amp brand

201580-1

TE Connectivity / AMP Brand

Contact - Multimate - Type II Series - Socket - Crimp - 20 AWG - Gold Plated Contacts. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 201580-1 is a Signal Socket Contact made of brass with gold-plated finish and crimp termination. This type II series socket accepts 24 to 20AWG discrete wire and can be used with CPC connectors, G series connectors, M series connectors.

Product Highlights:

  • Socket
  • Gold (30) over Nickel (50) Contact Mating Area Plating
  • Wire Range = 0.20-0.60² [24-20] mm [AWG]
  • Insulation Diameter = 1.02 - 1.57 mm
  • Brass Contact Material

Search Keywords: 2015801

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
201580-1
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Signal
Gender:
SKT
Contact Size:
16
Wire Size:
20-24 AWG
Contact Material:
Brass
Contact Plating:
Gold over Nickel
Maximum Current Rating:
N/A
Termination Method:
Crimp

IN STOCK: 15,310

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 5000

Factory Lead-Time 13 Weeks

Price (CAD)

Qty
Unit Price
10
$5.007
1,000
$3.782
2,500
$3.644
5,000
$3.522
10,000
$3.507
15,000
$3.491
20,000 +
$3.461
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Product Changes

Accessories

91538-1

CCII TYPE II PIN SKT 30-20 ASSY

58541-2

PRO-CRIMPER HAND TOOL DIE

1-601967-5

POSITIONER TYPE II CONTACTS

58541-1

PRO-CRIMPER HAND TOOL & DIE

200893-2

Insertion Tool for TYPE II, III+

305183

Extraction Tool For Type II, III, III(+), VI, X, and Subminiature Coaxial Contacts.

539972-1

Extraction Tool for Universal MATE-N-LOK; Socket Ø1.5; TYPE II, III+; CI-2, -3, -H; Econos ...
