202236-3 by te connectivity / amp brand
Image is representational - see mfr. specs

202236-3

TE Connectivity / AMP Brand

III+ PIN,SOLTAB,30AU<10,SMPACK ...

Datasheet
RoHS Non-Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

202236-3 is a precision pin contact with solder tab designed for use in MultiMate connector systems. The contact features a gold (30 µm) over nickel (50 µm) plating on the mating area for reliable electrical connection, with a copper alloy contact material and bright tin-lead termination end plating. The pin has a diameter of 1.57 mm (0.062 in) and is constructed with a stainless steel spring material, supporting a test current of 13.0 amps. This Type III+ contact is suitable for discrete wire termination in commercial-grade applications and is compatible with M Series and CPC connectors, making it ideal for signal transmission in industrial and commercial connector assemblies.

Product Highlights:

  • Pin with Solder Tab
  • Gold (30) over Nickel (50) Contact Mating Area Plating
  • Copper Alloy Contact Material
  • Bright Tin-Lead Termination End Plating
  • Type III+

Search Keywords: 2022363

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
202236-3
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Box
Contact Type:
Power
Gender:
Pin
Contact Size:
16
Wire Size:
N/A
Contact Material:
Copper Alloy
Contact Plating:
Gold over Nickel
Maximum Current Rating:
N/A
Termination Method:
Crimp
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 320

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 125

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
10
$6.22
25
$6.20
50
$6.19
125
$6.17
250
$3.80
375
$3.01
500 +
$2.95
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

200893-2

Insertion Tool for TYPE II, III+

305183

Extraction Tool For Type II, III, III(+), VI, X, and Subminiature Coaxial Contacts.

539972-1

Extraction Tool for Universal MATE-N-LOK; Socket Ø1.5; TYPE II, III+; CI-2, -3, -H; Econos ...

Show 1 More
