204521-2 by te connectivity / amp brand
Image is representational - see mfr. specs

204521-2

TE Connectivity / AMP Brand

AMPLIMITE,ASY,PLUG,STD,90,5 ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 204521-2 is a 78-contact (Shell Size 5) subminiature rectangular plug connector with pins, qualified to MIL-DTL-24308 military standards. It features dimensions of 2.079 inches (52.81 mm) length, 0.441 inches (11.2 mm) width, and 2.406 inches (61.11 mm) overall depth, with a contact spacing of 0.039 inches (0.99 mm). The connector uses AS39029 contacts (Pin M39029/58-360) rated for wire sizes 22–28 AWG with insulation diameters of 0.4–0.8 mm², offering reliable high-speed termination by automatic machine crimping. This connector is designed for military and industrial applications requiring compact, high-density interconnections in aerospace, defense, and telecommunications systems where durability and standardized performance are critical.

Product Highlights:

  • Connector
  • Product Series = 90
  • Density = High
  • Terminate To Wire
  • Number of Positions = 78

Search Keywords: 2045212

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
204521-2
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
5
Number of Contacts:
78
Shell Plating Material:
Cadmium/Steel
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 1

Ships today, if you order in

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
1 +
$38.90
