2-2170705-2

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

2-2170705-2

RoHS:

Yes

HTS:

8538908180

COO:

MY

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

24

Package Type:

Tray

Termination Method to Printed Circuit Board:

Through Hole - Press-Fit

Circuit Application:

Signal

Pluggable I/O Product Type:

Cage Assembly

Connector & Contact Terminates To:

Printed Circuit Board

Included Lightpipe:

Yes

Connector Mounting Type:

Board Mount

Sealable:

No

Cage Type:

Single

Cage Material:

Nickel Silver

Number of Rear EONs per Port Column:

2

Enhancements:

Standard

Data Rate (Max):

28 Gb/s

Heat Sink Style:

UL Flammability Rating:

UL 94V-0

PCB Contact Termination Area Plating Material:

Tin

Heat Sink Height Class:

SAN

EMI Containment Feature Type:

Internal/External EMI Springs

Form Factor:

QSFP28/56

Number of Ports:

1

Pluggable I/O Applications:

SFP+ Stacked Belly-to-Belly

Port Matrix Configuration:

1 x 1

Heat Sink Compatible:

Yes

Heat Sink Finish:

Anodized Black

Lightpipe Configuration:

Dual Round

Thermal Accessory Type Included:

Heat Sink

Connector System:

Cable-to-Board

For Use With Pluggable I/O Products:

QSFP28 Cable Assembly , QSFP28 MSA Compatible Transceiver

Operating Temperature Range:

-40 – 85 °C, -40 – 185 °F

Heat Sink Height:

.256 in, 6.5 mm

PCB Thickness (Recommended):

.062 in, 1.57 mm

Packaging Method:

Box & Tray

Termination Post & Tail Length:

.081 in, 2.05 mm
