2302785-1 by te connectivity / amp brand

2302785-1

TE Connectivity / AMP Brand

Conn Backplane PL 112 POS 1.8mm Solder RA Thru-Hole ...

Datasheet
RoHS Non-Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 2302785-1 is a high-quality connector designed for backplane applications. With 112 positions and a pitch of 1.8mm, this connector provides reliable and efficient connections for various electronic devices. It features solder termination and a right-angle through-hole mounting style, ensuring ease of installation and durability. This connector is an ideal choice for demanding applications where space is limited and high performance is required.

Search Keywords: 23027851

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2302785-1
RoHS:
No
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
Backplane3410
Gender:
PL3394
Body Orientation:
Right Angle3390
Mounting:
Through Hole3402
Pitch:
1.8 mm
Number of Contacts:
112
Termination Method:
Press Fit3409
Operating Temperature:
-55 to 125 °C

IN STOCK: 0

On Order: 1,038   can ship 12/18/25
On Order: 202   can ship 1/7/26

Factory Lead-Time 28 Weeks

Price (CAD)

Qty
Unit Price
1
$177.432
5
$172.930
10
$171.214
17
$161.919
34
$161.108
51 +
$154.187
Suppliers Standard Package
