2-32561-1

The 2-32561-1 is a pre-insulated (PIDG) flanged spade tongue terminal designed for solderless termination of 22-16 AWG wire. ...

Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 2-32561-1 is a PIDG (Pre-Insulated Diamond Grip) flanged spade tongue terminal for creating reliable, solderless connections. It is designed for a 22-16 AWG wire size and features a red nylon insulation sleeve for easy identification and high dielectric strength. The terminal accommodates a #6 or M3.5 stud and is constructed from tin-plated copper, which provides excellent corrosion resistance. Features such as a funnel entry for faster wire insertion and internal barrel serrations for high tensile strength make it suitable for a wide range of commercial and industrial applications requiring secure, insulated terminations.

Product Highlights:

Terminal Shape = Spade Tongue, Flanged
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 2325611

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

2-32561-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
