2-5748003-0 by te connectivity / amp brand

2-5748003-0

TE Connectivity / AMP Brand

09 PLUG SP/FMS BRDLK ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 2-5748003-0 is a 09 pin plug with a SP/FMS BRDLK design. This high-quality connector is designed to securely lock onto the corresponding receptacle, ensuring a reliable and secure connection for your electrical circuits. Its compact size and durable construction make it suitable for a wide range of applications in industries such as automotive, telecommunications, and industrial equipment. Trust TE Connectivity / AMP Brand for top-notch electrical components.

Product Highlights:

  • Number of Positions = 9
  • Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 257480030

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-5748003-0
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 596

Can Ship immediately

On Order: 1,071   can ship 12/3/25
On Order: 1,071   can ship 12/22/25

Minimum Order: 17

Multiple: 17

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
17
$3.770
51
$3.677
102
$3.605
255
$3.523
510
$3.502
1,003
$3.461
2,516 +
$3.440
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

1-747943-5

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1-745491-9

RCPT ASSY,9P,HDE,MS

1-747943-6

KIT,RCPT,9P,HDE,SHLD ENCLSRE

1658610-4

9 Position D-Sub Receptacle, Female Sockets Connector

1-745491-7

09 HDE MS RCPT,22-26,LEAD FREE

1-745491-6

09 HDE MS RCPT,26-30,LEAD FREE

1658612-4

09 POS HDF RCPT, MS, LEAD FREE

5746861-4

9 POS HDF RCPT, MS

747516-7

09 HDE PMOLD RCPT, LEAD FREE
